12v 48 LEDs 16 pixels ws2811

12v 48 dynamic dream color ws2811 LED strip

Product Description:

12v 48 LEDs/m ws2811 dream color LED strip
Mode: BW5050RGB48T-2811-12V

There are 48pcs of SMD5050 RGB + 10 IC ws2811 in one meter, each 3 LEDs as a separately segment/pixel, and each group of 3 LEDs can be cut off.

Parameter

1. Input DC12v, 12 watts/m

2. 48 LEDs/m, SMD5050 RGB

3. Drive IC ws2811, grey scale=256/color, 24 btis for RGB

4. 16 segments/pixel in one meter, each segment can be controlled individually

5. FPC width= 10mm, 3M tape backing

6. Wire out: DC12v, DATA, GND

7. TTL/SPT protocol.

Protection and mode:

IP rating	Protection	Outer Size	Installation	Mode
IP40	None	L5000*W10	Double side tape	BW5050RGB48T-2811-12v
IP65	Glue coating	L5000*W10	Double side tape	DW5050RGB48T-2811-12v
IP67	Silicone tube	L5000*W11	screw + buckle	TW5050RGB48T-2811-12v
IP68	Tube+glue filled	L5000*W11	screw + buckle	JW5050RGB48T-2811-12v
