5V 34 pixels/m DMX512 addressable LED strip
5V 34 pixels/m DMX512 addressable LED strip
Product Description:

 DC5v 34 LEDs/m DMX512 LED strip lights
Mode: BB5050RGB34T-DMX-5V

Overview:
DMX512/1990 protocol addressable RGB LED strips, special design for DMX512 control system, 34 individually pixel per meter and 102 channels per meter, about 5 meters per universe.


Parameter:

1. DC5v, MAX 10watts/meter;

2. 34 LEDs/m, 34 pixels/meter;

3. 1 LEDs as 1 segment;

4. 102 DMX channels per meter, 1 universe/512CH can drive MAX 5meters(1 roll);

5. SMD5050 RGB, Epistars chips;

6. Standard DMX512 interface:
 A/B/GND/5V

7. Packaging: 5 meter/roll.

IP rating Protection Outer Size Installation Mode
IP40 None L5000*W12 Double side tape BB5050RGB34T-DMX-5V
IP65 Glue coating L5000*W12 Double side tape DB5050RGB34T-DMX-5V
IP67 Silicone tube L5000*W13 screw + buckle TB5050RGB34T-DMX-5V
IP68 Tube +glue filled L5000*W13 screw + buckle JB5050RGB34T-DMX-5V


Advantages:

1.  DMX address increase automaticly from 1 to 512/1024/1536, NO need to set the address;

2. Each LED is individually controllable;

3. It is controllable with MADRIX / freestyle.
