D30 milky PVC ws2811 pixel RGB LED dot light
Product Description:
D30 milky PVC ws2811 pixel RGB LED dot light
Mode: D30S5050RGB3T-2811-12V
Parameter
1. Input DC12v, 0.72watts/pcs
2. 1pcs module is drove by 1pcs ws2811 IC
3. 3 × SMD5050 RGB per module, Epistar chips
4. 20pcs/string, Space = 8cm (side to side)
5. PCB size: Diameter=30mm
6. D3.5CM hole for installation
7. Epoxy coating on back PCB
8. 3 signal wires:
Data
GND
2 power wires:
DC12v
GND
Overview:
RGB Pixels are digitally-controllable lights you can set to any color, or animate. Each metal 'pixel square' contains 3 RGB LEDs and a controller chip soldered to a PCB--ws2811. Two metal flanges on the side and a 0.15"/3.5mm diameter hole in the middle to screw them directly onto a surface. The total max brightness of all LEDs is about 6000mcd.
The pixels are connected by a 3-conductor cable. +12VDC, ground, and data. Data is shifted down from one pixel to the next so that you can easily cut the strand or attach more onto the end.
Each dot is digitally controlled, with an internal 8-bit PWM LED driver (24-bit color for 16 million different shades). The pixels must be clocked by a microcontroller.
